Display Type

Color TFT LCD

Size

17 inch

Resolution

1280*1024

Brightness

400cd/㎡

Language

English, Simplified Chinese

Memory Capacity

10,000 waypoints, 10,000 markers, 500 routes, one route can indicate 200 waypoints

Interface

3 Ports NMEA0183 Output, 1 Ports AIS Input (Baud rate38400), 3 Ports NMEA0183 Input

Chart

S-57,S-63; CJ-57,CJ-63

CPU

Cortex-A17 Quad core 1.6GHz

Memory

2GB

Flash

16GB

WiFi

802.11 b/g/n

4G Module

LTE/GSM, Internal antenna, and support to connect external antenna

Ethernet

1000Mbps

Power Supply

DC18V~36V

Power Consumption

24W or less (24 VDC)

Enviromental

Working Temperature

-20℃~+60℃

Storage Temperature

-15℃~+55℃

Waterproof

IP65

GNSS

GNSS Receiver

72 channels

Receive Frequency

GPS L1: 1575.42MHz；BDS B1: 1561.098MHz

Accuracy

GPS&BDS

2.5m(CEP50% open sky)

GPS

5m(CEP50% open sky)

BDS

5m(CEP50% open sky)

Speed Accuracy

0.1m/s(50%@10m/s)

Time to First Fix

Cold Start <30s , Hot Start <1s

Standards

Comply with requirements in the《Maritime navigation and radio communication equipment and systems - General requirements- Methods of testing and required test results》.
Comply with the Class A equipment requirements in the《Electronic chart system

(ECS)-Operational, performance and test requirements》that issued by the China Maritime Safety Administration.
Comply with requirements in the《IHO Transfer standard for digital hydrographic data》that issued by International Hydrographic Organization.
Comply with requirements in the《IHO Data Protection Scheme》that issued by International Hydrographic Organization.
Comply with requirements in the《Specifications for Chart Content and Display Aspects of ECDIS》that issued by International Hydrographic Organization.
